Fourth generation (JL) · 2018–present
Jeep Wrangler
Every configuration's clearance, angles, weights and towing from Jeep's own documents, then what a lift and bigger tyres do to them.
- Approach
- 41.4–46.7°
- Clearance
- 9.7–11.1 in
- Tows up to
- 5,000 lb
- Configurations, all years
- 24
Spec plate
2026 Jeep Wrangler
One configuration per trim, named under each heading. Solid figures are the maker's; "door label" means the maker only prints it on each vehicle's certification label.
| SportWrangler Sport 4-door 3.6L manual | SaharaWrangler Sahara 4-door 3.6L automatic | RubiconWrangler Rubicon 4-door 3.6L manual | Moab 392Wrangler Moab 392 4-door 6.4L V8 automatic | |
|---|---|---|---|---|
| Ground clearance | 9.7 in | 10.0 in | 10.8 in | 11.1 in |
| Approach | 41.4° | 41.8° | 43.9° | 46.7° |
| Breakover | 20.3° | 21.0° | 22.6° | 24.5° |
| Departure | 36.1° | 36.1° | 37.0° | 39.8° |
| Wheelbase | 118.4 in | 118.4 in | 118.4 in | 118.4 in |
| Curb weight | 4,251 lb | 4,464 lb | 4,594 lb | 5,268 lb |
| Max payload | 1,249 lb | 1,136 lb | 1,381 lb | 1,088 lb |
| Max towing | 3,500 lb | 3,500 lb | 3,500 lb | 3,500 lb |
| Front axle rating | 2,700 lb | 2,700 lb | 3,100 lb | 3,400 lb |
| Stock tyres | P245/75R17 | P255/70R18 | LT285/70R17C | LT315/70R17C |
| Low range | 2.72:1 | 2.72:1 | 4:1 | 2.72:1 |
Build it
What a lift and bigger tyres do to a Wrangler
Lift
Tyres
Load
Ground clearance
11.1 in—
Maker
Clearance, rear diff
No data yet
No data yet
Approach
46.7°—
Maker
Breakover
24.5°—
Maker
Departure
39.8°—
Maker
Tyre diameter
34.4 in—
MakerLT315/70R17C
Speedometer
accurate—
Maker
Effective final drive
4.56:1—
Maker
Payload left
1,088 lb—
Maker
Front axle load
2,797 lb—
Maker
Rear axle load
2,471 lb—
Maker
Stock figures: 2026 Jeep Wrangler Specifications (spec sheet with towing capacities). Solid outline = from the maker; dashed = our estimate from geometry.
Part masses are typical, not yours. This is an estimate, not a weighbridge: weigh your rig.
