Fourth generation · 2024–present
Toyota Tacoma
Every configuration's clearance, angles, weights and towing from Toyota's own documents, then what a lift and bigger tyres do to them.
- Approach
- 32.8–35.7°
- Clearance
- 11.5 in
- Tows up to
- 6,500 lb
- Configurations, all years
- 27
_DSC_7353.jpg){kind=link}
Spec plate
2026 Toyota Tacoma
One configuration per trim, named under each heading. Solid figures are the maker's; "door label" means the maker only prints it on each vehicle's certification label.
| SRSR Double Cab 5-ft bed 4x4 6MT | SR5SR5 XtraCab 6-ft bed 4x4 | TRD PreRunnerTRD PreRunner XtraCab 6-ft bed 4x2 | TRD SportTRD Sport Double Cab 5-ft bed 4x4 6MT | TRD Off-RoadTRD Off-Road Double Cab 5-ft bed 4x4 6MT | LimitedLimited Double Cab 5-ft bed 4x4 | TrailhunterTrailhunter Double Cab 5-ft bed 4x4 i-FORCE MAX | TRD ProTRD Pro Double Cab 5-ft bed 4x4 i-FORCE MAX | |
|---|---|---|---|---|---|---|---|---|
| Ground clearance | 11.5 in | 10.7 in | 11.0 in | 11.5 in | 11.5 in | 11.5 in | 11.5 in | 11.5 in |
| Approach | 35.7° | 32.8° | 35.7° | 35.7° | 35.7° | 35.7° | 35.7° | 35.7° |
| Breakover | 27.4° | 23.8° | 24.6° | 27.4° | 27.4° | 27.4° | 27.4° | 27.4° |
| Departure | 25.3° | 22.1° | 22.6° | 25.3° | 25.3° | 25.3° | 25.3° | 25.3° |
| Wheelbase | 131.9 in | 131.9 in | 131.9 in | 131.9 in | 131.9 in | 131.9 in | 131.9 in | 131.9 in |
| Curb weight | 4,485 lb | 4,375 lb | 4,145 lb | 4,485 lb | 4,485 lb | 4,485 lb | 5,030 lb | 5,030 lb |
| GVWR | 5,865 lb | 5,605 lb | 5,605 lb | 5,865 lb | 5,865 lb | 5,865 lb | 6,665 lb | 6,665 lb |
| Max payload | 1,380 lb | 1,230 lb | 1,405 lb | 1,380 lb | 1,380 lb | 1,380 lb | 1,420 lb | 1,420 lb |
| Max towing | 3,500 lb | 6,500 lb | 6,500 lb | 6,400 lb | 6,400 lb | 6,400 lb | 5,950 lb | 5,950 lb |
| Stock tyres | 245/70R17 | 245/70R17 | 265/70R17 | 265/65R18 | 265/70R17 | 265/65R18 | 265/70R18 | 265/70R18 |
| Low range | 2.57:1 | 2.57:1 | n/a | 2.57:1 | 2.57:1 | 2.57:1 | 2.57:1 | 2.57:1 |
Generations
Toyota · US
Tacoma
Fourth generation · 2024–present
- Approach
- 32.8–35.7°
- Clearance
- 11.5 in
- Tows up to
- 6,500 lb
2026 · 27 configurations · 263 sourced numbers · 63% of builder fields
Toyota · US
Tacoma
Third generation · 2016–2023
- Approach
- 29.0–36.4°
- Clearance
- 9.4 in
- Tows up to
- 6,500 lb
2023 · 34 configurations · 210 sourced numbers · 68% of builder fields
Build it
What a lift and bigger tyres do to a Tacoma
Stock figures: 2023 Tacoma Product Information. Solid outline = from the maker; dashed = our estimate from geometry. Overhangs are estimated (the maker doesn’t publish them), so changed angles carry a range.
Part masses are typical, not yours. This is an estimate, not a weighbridge: weigh your rig.
