Fourth generation (XU70) · 2020–present
Toyota Highlander
Every configuration's clearance, angles, weights and towing from Toyota's own documents, then what a lift and bigger tyres do to them.
- Approach
- 18.1°
- Clearance
- 8.0 in
- Tows up to
- 5,000 lb
- Configurations, all years
- 7
Spec plate
2026 Toyota Highlander
One configuration per trim, named under each heading. Solid figures are the maker's; "door label" means the maker only prints it on each vehicle's certification label.
| XLEXLE AWD | XSEXSE AWD | LimitedLimited AWD | PlatinumPlatinum AWD | |
|---|---|---|---|---|
| Ground clearance | 8.0 in | 8.0 in | 8.0 in | 8.0 in |
| Approach | 18.1° | 18.1° | 18.1° | 18.1° |
| Departure | 23.4° | 23.4° | 23.4° | 23.4° |
| Wheelbase | 112.2 in | 112.2 in | 112.2 in | 112.2 in |
| Curb weight | 4,376 lb | 4,420 lb | 4,453 lb | 4,453 lb |
| GVWR | 5,970 lb | 5,970 lb | 5,970 lb | 5,970 lb |
| Max towing | 5,000 lb | 5,000 lb | 5,000 lb | 5,000 lb |
| Stock tyres | P235/65R18 | P235/55R20 | P235/55R20 | P235/55R20 |
| Low range | n/a | n/a | n/a | n/a |
