Sixth generation · 2025–present
Toyota 4Runner
Every configuration's clearance, angles, weights and towing from Toyota's own documents, then what a lift and bigger tyres do to them.
- Approach
- 18.0–33.0°
- Clearance
- 8.1–10.1 in
- Tows up to
- 6,000 lb
- Configurations, all years
- 16
Spec plate
2026 Toyota 4Runner
One configuration per trim, named under each heading. Solid figures are the maker's; "door label" means the maker only prints it on each vehicle's certification label.
| SR5SR5 4x4 | TRD SportTRD Sport 4x4 | TRD Sport PremiumTRD Sport Premium 4x4 | LimitedLimited 4x4 | TRD Off-RoadTRD Off-Road 4x4 | TRD Off-Road PremiumTRD Off-Road Premium 4x4 | PlatinumPlatinum 4x4 i-FORCE MAX | TrailhunterTrailhunter 4x4 i-FORCE MAX | TRD ProTRD Pro 4x4 i-FORCE MAX | |
|---|---|---|---|---|---|---|---|---|---|
| Ground clearance | 8.1 in | 8.8 in | 8.8 in | 8.8 in | 9.1 in | 9.1 in | 8.8 in | 10.1 in | 10.1 in |
| Approach | 18.0° | 18.0° | 18.0° | 18.0° | 19.0° | 19.0° | 18.0° | 33.0° | 33.0° |
| Breakover | 23.0° | 24.0° | 24.0° | 24.0° | 24.0° | 24.0° | 24.0° | 24.0° | 24.0° |
| Departure | 22.0° | 22.0° | 22.0° | 22.0° | 24.0° | 24.0° | 22.0° | 24.0° | 24.0° |
| Wheelbase | 112.2 in | 112.2 in | 112.2 in | 112.2 in | 112.2 in | 112.2 in | 112.2 in | 112.2 in | 112.2 in |
| Curb weight | 4,685 lb | 4,850 lb | — | 4,970 lb | 4,850 lb | — | 5,390 lb | 5,500 lb | 5,455 lb |
| GVWR | 6,075 lb | 6,395 lb | — | 6,395 lb | 6,240 lb | — | 6,505 lb | 6,505 lb | 6,505 lb |
| Max towing | 6,000 lb | 6,000 lb | 6,000 lb | 6,000 lb | 6,000 lb | 6,000 lb | 6,000 lb | 6,000 lb | 6,000 lb |
| Stock tyres | 245/70R18 | 265/55R20 | 265/55R20 | 265/55R20 | 265/70R18 | 265/70R18 | 265/55R20 | 265/70R18 | 265/70R18 |
| Low range | 2.57:1 | 2.57:1 | 2.57:1 | 2.57:1 | 2.57:1 | 2.57:1 | 2.57:1 | 2.57:1 | 2.57:1 |
Generations
Toyota · US
4Runner
Sixth generation · 2025–present
- Approach
- 18.0–33.0°
- Clearance
- 8.1–10.1 in
- Tows up to
- 6,000 lb
2026 · 16 configurations · 120 sourced numbers · 50% of builder fields
Toyota · US
4Runner
Fifth generation · 2010–2024
- Approach
- 30.0–33.0°
- Clearance
- 9.0–9.6 in
- Tows up to
- 5,000 lb
2024 · 11 configurations · 93 sourced numbers · 56% of builder fields
Build it
What a lift and bigger tyres do to a 4Runner
Stock figures: 2026 4Runner Product Information. Solid outline = from the maker; dashed = our estimate from geometry. Overhangs are estimated (the maker doesn’t publish them), so changed angles carry a range.
Part masses are typical, not yours. This is an estimate, not a weighbridge: weigh your rig.
